Drone Geprc Cinepro: prezzi e offerte

Caratteristiche tecniche e funzioni Geprc Cinepro

STABLE PRO F722 DUAL Gyro ICM20689 Version:

Flight Controller：
Model:STABLE PRO F7 35A
MCU: STM32F722RET6
IMU: 2x ICM20689(SPI)
BlackBox: 32Mb onboard Flash
OSD: BetaFlight OSD w/ AT7456E chip
Firmware target: EXF722DUAL
Integrated LC Filter
Size: 26x26mm board, 20mm mounting holes (M2)
ESC BLheli_32 2-6S 4in1：

MCU:STM32F051
Constant:35Amps
Burst:45Amps
Mounting Holes:20*20mm,M2
Supports Dshot1200,Proshot,Oneshot,Multishot
Current meter: Yes
Target: GEPRC-BL32-4IN1
5.8g 500mW VTX:

Input voltage: 5V
Channel: 48
Power transmission: 0mW(Pit mode) / 25mW / 100mW / 200mW / 400mW/ 500mW
Connector type: MMCX Connector
Traditional button
IRC Tramp protocol

STABLE V2 F405 Version:

Flight Controller：
Model:STABLE V2 F4 30A
MCU: F405
IMU: MPU6000 gyro/accelerometer (SPI)
OSD: BetaFlight OSD w/ AT7456E chip
Baro:NO
BEC Output: 5V@3A
Integrated LC Filter
Firmware target: OmnibusF4SD
BLheli_S ESC 2-5S 4in1：

MCU:STM32F051
Input:2-6s lipo
Constant:35Amps
Burst:45Amps
Supports Dshot1200,Proshot,Oneshot,Multishot
Current meter: Yes
Target: GEPRC-BL32-4IN1
5.8g 500mW VTX:

Input voltage: 5V
Channel: 48
Power transmission: 0mW(Pit mode) / 25mW / 100mW / 200mW / 400mW/ 500mW
Connector type: MMCX Connector
Traditional button
IRC Tramp protocol

Feature introduction:
F722 flight control, STABLE PRO F722 DUAL BL32 35A (advanced version)
F405 flight control, STABLE V2 F405 30A (basic version)
Using the GEP-GR1105 5000KV motor, 4S battery is recommended (450-650mAh)
Weight: 127g (without battery)
Wheelbase: 115mm
